Audison Thesis TH uno

The Audison Thesis TH uno is a 1-Channel Amplifier in A-Class design with integrated 24-bit/192 kHz DA converters and compatibility with Audison Full DA HD technology. SPDIF and AD-Link optical inputs support up to 8 digital channels at the RJ-45 connection. The minimum impedance is 1 Ω and the total RMS power is 1500 W. The bandwidth is 5 – 40 kHz, the S/N ratio (A-weighted @1 V) is 106 dBA, and the damping factor is 500. Dual-Mono construction with four power supplies in Synchro-PWM configuration and a chassis made from extruded aluminum CNC are included. A sensitivity control with 256 steps and 120 dB resolution, selectable presets for energy saving, Hi-Current, Hi-AB Class, and A Class, as well as digital control via integrated setting field, DRC, and PC software are available. Low Level Input is present, Hi Level Input is not. Features 1-Channel Amplifier Amplifier Class: A-Class Total RMS Power: 1500 W Output Power (RMS) @ 4 Ω: 850 W x 1 Output Power (RMS) @ 2 Ω: 1500 W x 1 Output Power (RMS) @ 1 Ω: 2300 W x 1 Minimum Impedance: 1 Ω SPDIF and AD-Link optical inputs (up to 192 kHz/24 bit) Supports up to 8 digital channels at the RJ-45 connection Integrated 24-bit/192 kHz DA converter Dual-Mono construction with four power supplies in Synchro-PWM configuration Sensitivity control with 256 steps and 120 dB resolution Presets: Energy saving, Hi-Current, Hi-AB Class, A Class (selectable in real-time) Digital control via integrated setting field, DRC, and PC software Crossover module included Chassis made from extruded, CNC-crafted aluminum Low Level Input: Yes Hi Level Input: No Linked Amplifiers: Master/Slave Bridged; Slave Chain Technical Specifications Channels: 1 Supply Voltage: 11 – 15 VDC Fuse: 150 A Idle Current when Off: 0.04 mA Power Consumption @ 14.4 VDC, 2 Ω, maximum music power: 132 A Remote OUT: 12 VDC (20 mA) Remote IN: 7 – 15 VDC (1 mA) Distortion (THD) @ 100 Hz, 4 Ω, 70 % rated power: 0.01 % Bandwidth (-3 dB, 2 VRMS, 4 Ω): 5 – 40 kHz S/N Ratio (A-weighted @ 1 V): 106 dBA Damping Factor (1 kHz, 4 Ω): 500 Input Sensitivity Pre-In: 0.3 – 4.8 VRMS Input Impedance Pre-In: 15 kΩ Adjustable Crossover: No CEA Output Power @ 4 Ω, 1 % THD+N, 14.4 V: 700 W x 1 channel CEA S/N Ratio (ref. 1 W output): 75 dBA Inputs: PRE and S/PDIF (optical, up to 192 kHz/24 bit) and AD Link Filter Outputs: PRE Bypass / AD Link Filter Pass: Removable kit, Hi-pass/Lo-pass/Bandpass 12/24 dB, 32 steps, 18 – 7.5 kHz, 8 standard and 2 customizable modules Weight: 10.3 kg Dimension A: 510 mm Dimension B: 478 mm Dimension C: 259 mm Dimension D: 160 mm
