Rockford Fosgate PMX-HD9813 Harley Motorcycle Radio

The Rockford Fosgate PMX-HD9813 is a Harley-Davidson Motorcycle Multimedia Receiver with 4-volt preamp outputs, wireless Bluetooth 3.0+EDR including A2DP and AVRCP, digital AM/FM/WB tuner with presets, and SiriusXM-Ready. The 76.2 mm color TFT display offers a day/night mode. The receiver supports Pandora, features a USB input with 1.5 A charging capability, AUX inputs, and retains the factory thumb control function without additional parts. A voltage meter with under-voltage warning, plug-and-play installation with electrical OEM connectors, 7-band graphic EQ plus PEQ, and an independent Subwoofer level controller are integrated. A selectable HP/LP/AP crossover with 12/24 dB/octave, software updates via USB, radio frequencies in multiple regions, and compatibility with the PMX-BTUR remote control are included. The PMX-HD9813 is designed as a direct replacement digital media receiver for 1998–2013 Harley-Davidson models. Features Harley-Davidson Motorcycle Multimedia Receiver 1998–2013 Harley-Davidson direct replacement digital media receiver 76.2 mm TFT color display with day/night mode Wireless Bluetooth 3.0+EDR with A2DP and AVRCP Pandora internet radio control Digital AM/FM/WB tuner with presets SiriusXM Ready, requires SXV300 tuner USB input with 1.5 A USB charging AUX inputs Retains the factory thumb control function without additional parts Voltage meter with under-voltage warning Plug-and-play installation with electrical OEM connectors 7-band graphic EQ + PEQ Independent Subwoofer level controller Compatible with PMX-BTUR remote control Radio frequencies in multiple regions Selectable HP/LP/AP crossover with 12/24 dB/octave Software updatable via USB Antenna not included Compatibility: Street Glide 2006–2013, Road Glide 1998–2013, Electra Glide 1998–2013 Technical Specifications Output impedance: < 500 Ohm Operating voltage: 9.5–16 VDC CEA-2006 rated power RMS power: 25 W x 4 at 4 Ω Maximum power: 50 W x 4 at 2 Ω THD+N: ≤ 1.0 % Idle current: < 2 A Frequency response RCA: 20 Hz – 20 kHz Frequency response High-Level: 20 Hz – 20 kHz THD+N 4-Ohm: < 1.0 % Crossover Sub-Out: variable 60 Hz – 120 Hz RCA output voltage Front: max. 4 V RCA output voltage Rear: max. 4 V RCA output voltage Subwoofer: max. 4 V Channel separation RCA: > 50 dB Channel separation High-Level: > 50 dB Signal-to-noise ratio RCA 2 V: > 85 dB Signal-to-noise ratio High-Level (CEA-2006): > 75 dB Max. Wrms: > 80 dB AM tuner range: 530 – 1710 kHz AM sensitivity: 40 dB AM frequency response: 45 – 2.4 kHz FM tuner range: 87.9 – 107.9 MHz FM sensitivity: 8 dB FM frequency response: 20 – 15 kHz Bluetooth: 3.0+EDR A2DP: 1.3 USB version: 2.0 USB output current: 1.5 A Supported media formats: MP3, WMA USB capacity: 32 Gb max Maximum file structure: 255 folders, 999 songs Windows USB file system: FAT32 Mac USB file system: MS-DOS (FAT) Clock: Yes Display size: 76.2 mm color TFT Resolution: 960 x 240 Pixels: 320 x 240 Brightness: 380 cd/m² Contrast: 400 Viewing angle: 120 Shipping...
